Welding power source
|
240V/480VAC – 25%+10%, 50/60Hz
|
|
Control power source
|
240VAC 20%, ± 50/60Hz
|
|
Number of schedules
|
15 schedules
|
|
Value No
|
1 or 2 can be selected for 15 schedules. 240VAC is output
|
|
Secondary output current range
|
5 – 80 kA
|
|
Setting of upper limit
Setting of lower limit
|
0% - 49%
0% - 49%
|
|
Total counter
-Present
-Weld counter
-Work counter
|
0 – 9999, 1 schedule
0 – 99, 1 schedule
0 – 9999, 1 schedule
|
|
Stepper up of current
|
Step: 1 - 9, rate: 50 – 200%
|
|
Control method
|
Constant current feedback control
|
|
Maximum current limit setting function
|
5 – 80 kA
|
|
Current monitor function
|
Upper limit 0 – 49%
Lower limit 0 – 49%
|
|
Weld current setting
|
Weld I, Welding II, Welding III
|
|
Operating ambient temperature
|
0 - 45° C
|
|
*Please note that the duty cycle value may varies according to room temperature.
|
