(Click on the pictures above to enlarge)
Product Quick Specifications:
* Input Voltage : 230 / 240V
* Input Current : 65A
* Welding Current : 8 KVA
* Duty Cycle : 50%
* Weight : 37Kg
* Dimensions (mm) : 373 x 273 x 380
Product Full Specifications:
| |
| |
|
TECHNICAL CHARACTERISTICS
|
MC 8
|
|
Primary Supply
|
50 / 60 Hz (1ph V)
|
AC230 / 240V, +15% - 20%
|
|
Rated Capacity at 50% Duty Cycle
|
KVA
|
8
|
|
No Load Voltage
|
KVA
|
6
|
|
Primary Line Current (Max)
|
A
|
65
|
|
Net Weight
|
Kg
|
36.5
|
|
Dimension (LxWxH)
|
mm
|
373x273x380
|
|
*Please note that the duty cycle value may varies according to room temperature.
|
|
|
| |
|
|
| |
Accessories |
|
| |
| |
:Portable spot gun
|
